Video input: 7 channel (1,080/1,080i/720 pixels)
-
Video output: 1 channel HDMI, 1 channel VGA
-
Audio input: 4 channel RCA
-
Audio output: 1 channel RCA
-
Sensor input/alarm output: 4/1 channel
-
Operating system: embedded Linux
-
HDMI output: 1,920 x 1,080 pixels, 1,920 x 1,080i
-
VGA output: 1,024 x 768, 1,280 x 1,024, 1,440 x 900, 1,920 x 1,080 pixels
-
Split screen: 1/4/7/9
-
Compression (video/audio): H.264/ADPCM
-
Picture quality: 3 steps (best, good, standard)
-
Record mode: normal/alarm/motion/audio event/duration/schedule
-
Total frames:
-
NTSC: 210fps at 1,080 pixels
-
PAL: 175fps at 1,080 pixels
-
Split display: 1/4/7/9
-
Search modes: date and time, calendar, event (alarm/motion), bookmark
-
Speed: forward (x1/2/4/8/16), backward (x2/4/8/16)
-
Protocols: TCP/IP, SMTP, HTTP, DHCP, PPPoE (ADSL)
-
Serial communication: RS485 x 2 (PTZ and keyboard control)
-
Web browser: Internet Explorer 5.0 higher
-
Event transport: E-mail, notification with JPEG when event occurs
-
Monitoring software: PC client, CMS, mobile viewerArchive devices: USB2.0 x 2
-
Motion detection area: programmable motion detection area for each camera
-
Motion detection sensitivity: 3 steps for each channel
-
Alarm hold-time: 5-240 seconds
-
Event log: up to 2,500 events (alarm/motion/video and power loss and more)
-
PTZ control: IR Remocon/mouse/keyboard, RS485 interface (Pelco-P/D)
-
Supports internal 2 x HDD up to 6TB
-
Voltage: 12V DC, 3.5A
-
Power consumption: 40W
